Technical Parameter
| Film Width | 420mm/520mm |
| Bag Length | 80-300mm or larger |
| Bag Width | 60-200mm or larger |
| Film Roll Diameter | Max 320mm |
| Packing Rate | 5-30bag/min |
| Measurement range | 150-1500ml |
| Film Thickness | 0.04-0.08mm |
| Power | 220V 50Hz 2.2kv |
| Machine Size | (L) 1217 (W) 1015 (H) 1343 |
| Machine Weight | 420kg |
DATE PRINTING can be integrated.
Main Features and Functions :
1) New design, nice appearance with SUS304 build up, more advance technology.
2) PLC computer control system; color touch screen control; easy to use
3) Servo motor control film pulley; accurate positioning for film stop and draw.
4) Fully automatic with alarm notification
Optional Device :
1) Gusset Forming
2) Breath Valve on Packaging Bag
3) Gas Blower
Scope of application :
Puffed Food, Snack Foods, Crispy Rice, Dried Fruit, Chocolate, Hardware Items and Etc
Compositions :
1) Z Shape Elevator
2) 10 Heads Weighing Machine
3) Vertical Packing Machine
4) Platform (Optional)
5) Finished Products Conveyor
