| Film width | Max.350mm |
| Bag length | 65~190mm Or 120~280mm |
| Bag width | 50~160mm |
| Product height | Max. 45mm |
| Film roll diameter | Max.320mm |
| Packing speed | 40~230 pack/minute |
| Power supply | 220V,50/60HZ,2.8KVA |
| Machine size | (L)4020X(W)720X(H)1320 |
| Machine weight | 900Kg |
Suitable for packaging soft , strip and unorganized objects like bun, bread, kek, slice kek and more soft products.
Food contact parts is sttainless steel 304, food grade.
I. Main performance and structure features
1. Double transducer control, flexible bag length cutting, operator needn't to adjust the unloading working, saving time and saving films.
2.human-machine operation, convenient and quick parameter setting.
3.Self diagnosis failure function, clear failure display.
4. High sensitivity optical electric color mark tracking £¬digital input cut position which makes the sealing and cutting more accurate.
5. Separate PID control to temperature, suitable for various packing materials.
6. Stopping the machine in selected position, no sticking to the knife and no waste packing film.
7. Simple driving system, reliable working, convenient maintenance.
8. .All the controls are achieved by software, convenient for function adjusting and upgrading.
II. Application
Suitable for packaging soft , strip and unorganized objects like towels , tissues , noodles , egg rolls , sausages , fish , ice-lollipop , soft candies , biscuits , fresh fruits , etc.
